**First, GPRS Introduction**
GPRS stands for General Packet Radio Service. It is a mobile data service that was introduced for GSM (Global System for Mobile Communications) users and represents a key advancement in second-generation mobile communication technology. GPRS can be considered an evolution of the traditional GSM network, as it uses a packet-switched transmission method instead of the earlier circuit-switched approach.
Unlike the previous method where a dedicated channel was maintained throughout the entire session, GPRS transmits data in packets. This means that users are billed based on the amount of data they transfer rather than the time they remain connected. As a result, GPRS offers more cost-effective usage, especially for intermittent data transfers such as email or web browsing.
In terms of speed, GPRS can achieve data rates of up to 115 kbps, with some configurations reaching as high as 171.2 kbps (excluding Forward Error Correction). This makes it possible for mobile users to access the internet at speeds comparable to ISDN, enabling a range of multimedia applications that require faster transmission.
**GPRS Advantages:**
1. **Low Connection Cost and High Resource Utilization:**
GPRS introduces a packet-switched mode into the GSM network, which significantly improves wireless resource efficiency. In a circuit-switched system, a user would occupy a channel continuously even if no data was being transmitted. However, with GPRS, users only use resources when sending or receiving data, allowing multiple users to share the same channel efficiently. Billing is based on data volume, following the "pay-as-you-go" principle. Even with long connection times, users typically pay only a small fee.
2. **High Transmission Speed:**
GPRS provides a maximum data rate of 115 kbps (up to 171.2 kbps without FEC), making it suitable for fast internet access and real-time multimedia services. With this speed, users can browse the web, send emails, or stream content with performance similar to wired connections.
3. **Fast Access Time:**
GPRS reduces the time required to establish a connection, typically under one second. This makes it ideal for applications that require quick and responsive data transfers.
4. **Efficient Use of Network Resources:**
The GSM air interface can support both voice and GPRS data traffic. When there are enough channels available, some can be dedicated to GPRS. To implement a GPRS network, new nodes like the GPRS Support Node (GSN) must be added to the existing GSM infrastructure. Additionally, mobile devices must be GPRS-enabled or operate in dual-mode (GSM/GPRS).
**Second, GPRS Module Setup Steps**
1. **Register for a Peanut Shell Account:**
Create an account and obtain a domain name. Set up dynamic DNS on your router and log in to the platform.
2. **Download Peanut Shell Software:**
Install the software on your computer, log in, and add the domain name link. This is a common method for dynamic domain name resolution.
3. **Configure Router Settings:**
Map the local MAC address to a fixed IP address. In the virtual server settings, assign a specific port number to that IP. For example, set port 2323 for IP 192.168.1.99.
4. **Set a Fixed IP on Your Computer:**
Configure your local computer’s network settings with a static IP address, such as 192.168.1.99, subnet mask 255.255.255.0, and gateway 192.168.1.1.
5. **Configure the GPRS Module:**
Use the module setup software to adjust parameters. Select the correct serial port, open it, and change the network connection to your domain name. Choose your SIM card provider and set the appropriate port (e.g., 2323). Once the settings are complete, confirm the success message.
6. **Install Virtual Serial Port Software on the Server Side:**
On the network-side computer, install the virtual serial port software. Create a TCP server configuration with the same port number you set earlier (e.g., 2323).
7. **Restart the GPRS Module:**
After restarting, wait for the network light to flash and the data light to turn on. At this point, both devices should be able to communicate successfully.
